Visaton W300 hifi woofer 12" 4 ohm 120W

Visaton W300 12" (30cm) 4 ohm hifi lagetonen luidspreker met foam surround.

Artikelnummer 9068

• P_RMS 120W
• P_MUS 180W
• Frequency response f_c -3000Hz
• Mean sound pressure level     91 dB (1 W/ 1m)
• Excursion limit     28 mm
• Resonance frequency fs     32 Hz
• Magnetic induction     0,95 Tesla
• Magnetic flux     1250 µ Weber
• Height of front pole-plate     8 mm
• Voice coil diameter     5 cm
• Height of winding     1,8 cm
• Cutout diameter     28 cm
• Net weight     2,8 kg
• D.C. resistance Rdc     3,8 Ohm
• Mechanical Q factor Qms     2,77
• Electrical Q factor Qes     0,56
• Total Q factor Qts     0,46
• Equivalent volume Vas     190 l
• Effective piston area Sd     490 cm2
  Dynamically moved mass Mms     43 g
  Force factor Bxl     8,3 T · m
  Inductance of the voice coil L     1,07 mH
